Pneumatic Diaphragm Valve with Positioner
Standard: | 3A/SMS/DIN | |||
| Body construction: | U type, straight type, three way | |||
Connection: | Welded, clamped, threaded | |||
| Warranty: | 1 year | |||
| Certification: | CE, ISO | |||
| Customized support: | OEM, ODM | |||
Size: | DN20~DN65, 3/4"~2 1/2" | |||
Working Principle:
The diaphragm provides the body seal as well as the seat seal. There are no paths to the outside environment and, as such, the valve is suitable for aseptic processes. When the valve is being closed, a pressure pad which supports the diaphragm moves towards the sealing face on the body. As the pressure plate moves, the diaphragm flexes and is forced down onto the seat area in the centre of the body, thus, closing off the flow path through the body.The inter-relationship of body to the pressure plate prevents over compression of the diaphragm.
This diaphragm valve with positioner is actuated pneumatically. If you are interested in this valve, please be free to contact us for more details. And our catalog is also available.
