Stainless Steel Solvent Recovery Tank for Closed Loop Extractor

Stainless steel solvent recovery tank,capacity from 20LB to 200LB are used for closed loop extractors,store and recovery solvent after each run.The tank can be with/without cooling coil,dip tube,and with jacketed versions
Availability:
Quantity:
  • 20LB
  • Sunthai extractor
  • SS304

This stainless steel solvent recovery tank is designed with a 4" center opening for sanitary clean-outs, Safety Ring to prevent damage to valve bodies as well as easy maneuvering and lifting. Also with bottom crush proof ring to prevent accidental damage to the lower body of the vessel. The tank body features a certified 3A sanitary mirror finish both inside and out standard for food grade and medical processing environments.

Stainless steelSS304
Capacity20LB to 200LB
PolishSantiary mirror polish
Jacket versionnon jacket,single jacket,double jacket
Port size1/4"FNPT,3/8" or 1/2" MNPT
Tri clamp opening top4",6" end cap
Optionswith or without coil,dip tube
Accessories can be added if requestBall valve,Sight glass,pressure gauge,jic fittings,pressure relief valve,etc

Example:

25 lbs tank. capacity at 80%.

4" tri-clamp lid allows you to clean out the tank.

(2) 1/4" MNPT ports.

(1) 14" dip tube.

(1) 1/4" FNPT.

(1) 1/4" FNPT.

Please tell us your detailed requirements,we can custom to order
